EN 10025-6 S890ql Steel Plate equivalent
S890ql steel plate is a highly welded structural steel grade according to EN 10025 standard. En 10025-6 S890ql sheet is treated with a quench and fire process for better bending and performance. En 10025-6 S890ql is three times stronger than S275 structural steel and is relatively easy to weld and weld.
The S890QL plate has a premium strength of 890 MPa, which decreases as it gets thicker. For construction also bridges and sea connections. They are often used in heavy duty trucks and cars. Trailers, agricultural, mining and earthmoving equipment, etc.
As a Manufacturer of high strength steel plates, Our S890ql series includes high-yield steel plates made of various combinations of carbon steel, carbon manganese steel, high-strength low-alloy steel, high-strength tempered and quenched low-alloy steel.
EN 10025-6 S890ql Steel Plates Specification
Thickness (H) 8-100 mm
Width (B) 2000-3200 mm
Length (L) 6000-12000 mm
EN 10025 includes a range of high strength quenched and tempered steel grades.
Minimum yield strength of 890 MPa.
S890ql Steel Plate meaning
The code “S” means structural steel.
890 = minimum yield strength (MPa)
The code “Q” refers to the delivery condition, in this case to quenched & Tempered.
The code “L” means that the average minimum values for impact energy have been defined at a temperature of -40°C.
Equivalent Grades of EN 10025–6:2004 S890QL Steel Plate
| GRADE | STANDARDS | WNR No. |
|---|---|---|
| S890QL | EN 10025-6 | 1.8983 |
S890QL Plate Chemical Composition
| C | SI | MN | P | S | B | CR | CU | MO |
|---|---|---|---|---|---|---|---|---|
| 0.20 | 0.80 | 1.70 | 0.020 | 0.010 | 0.005 | 1.50 | 0.50 | 0.70 |
| N | NB* | NI | TI* | V* | ZR* | |||
| 0.015 | 0.06 | 2.0 | 0.05 | 0.12 | 0.15 |
Hot Products
EN10025-6 Standard Steel Products
Get to know more about EN 10025-6 S890ql Steel Plate equivalent, please contact us.
EN 10025-6 S890QL Structural Steel Plate Mechanical Properties
| PLATE THICKNESS MM | YIELD STRENGTH REH (MPA) | TENSILE STRENGTH RM (MPA) | ELONGATION A5 % MINIMUM | IMPACT STRENGTH J, MINIMUM |
|---|---|---|---|---|
| 3 to50 | 890 | 940 – 1100 | 11 | 30 @ -40º C |
| 50to 100 | 830 | 880 – 1100 | 11 | 30 @ -40º C |
V-notch impact Testing of S890QL Structural Steel Plate:
| Grade | Sample Orientation | @ 0°C | @-20°C | @-40°C | @-60°C |
|---|---|---|---|---|---|
| S890QL | Longitudinal | 50 J | 40 J | 30 J | –– |
| Traverse | 35 J | 30 J | 27 J | –– |
Industry News
Smelting, rolling and composition properties of S890QL steel plate
S890QL steel plate is a high-strength structural steel plate with European standard, and the corresponding number is 1.8983. The rolling size of S890QL steel plate: thickness: 8-100mm, width: 1600-4020mm, length: 6000-17500mm.
What is S890QL steel equivalent carbon content
API 5L X70 pipeline steel belongs to ultra-low carbon microalloyed steel. The production of API 5L X70 pipeline steel has almost applied all the new technological achievements in the field of metallur
Lost wax EN10025-6 grade S890QL investment casting
BBN company team and culture: tt the end of 2019, in order to thank employees for their hard work and enrich their sparetime lives, the company organized a pleasant trip to Phuket Island, Thailand. T
BBN steel S890QL steel equivalent chemical composition supplier
Mechanical properties of S420NL-Z35 steel plate: yield strength≥235Mpa, tensile strength 360-510Mpa, elongation≥26%. The properties of S890QL steel equivalent, S420NL-Z35 steel plate determine i
EN 10025-6 high strength steel
Application
-
-
Port Cranes
-
Flatbed Trucks
-
Quarry Trucks
-
Articulated Dump Trucks
-
Mechanical Handling
EN 10025 S890QL Steel Plate is used in applications such as cranes (mobile and loader), aerial platforms, and load handling equipment, bridges, and special containers. These S890QL Plates are available in different shape size and thickness according to the needs of our customers and also available in customized specifications at affordable prices.
-
